Electrofusion Transition Elbow
Our electrofusion transition elbow joins two pipes of different diameters. This product is a key part for changing pipe size in your line. We keep common sizes like 63x50 and 90x63 in stock. So you get this product fast when you need it for an urgent job. There is no minimum order for this product. You can buy just a few pieces for a small repair. You can also mix this electrofusion transition elbow with other fittings in one order. We pack and ship them together. This saves you money on shipping. If damage happens during transport and it is our fault, we send a new product for free. This is our promise to you.
Description
Connect Two Different Sizes
Our electrofusion transition elbow joins two pipes of different diameters. This product is a key part for changing pipe size in your line. We keep common sizes like 63x50 and 90x63 in stock. So you get this product fast when you need it for an urgent job. There is no minimum order for this product. You can buy just a few pieces for a small repair. You can also mix this electrofusion transition elbow with other fittings in one order. We pack and ship them together. This saves you money on shipping. If damage happens during transport and it is our fault, we send a new product for free. This is our promise to you.
Key Data for On-Site Work
The table below gives you three important numbers. H1 is the big end socket depth. H2 is the small end socket depth. L is the total length. For example, size 250x200 has H1=161mm, H2=136mm, and L=255mm. Use these numbers to check your work before welding. Our team answers your questions fast. We have a special person for after-sales support. You can ask for a free sample of this electrofusion transition elbow. Test it on your site. See how well it fits and welds. Then order in bulk. We ship from our large stock. Choose our product for reliable size changes in your pipeline.
Clear Technical Data Table
|
Size dn1xdn2 |
Order Code |
dn1xdn2 |
H1 (mm) |
H2 (mm) |
L (mm) |
|
25x20 |
25/20 |
25x20 |
35 |
30 |
100 |
|
32x25 |
32/25 |
32x25 |
36 |
31 |
100 |
|
40x32 |
40/32 |
40x32 |
44 |
41 |
102 |
|
50x32 |
50/32 |
50x32 |
50 |
41 |
107 |
|
50x40 |
50/40 |
50x40 |
50 |
44 |
110 |
|
63x32 |
63/32 |
63x32 |
60 |
40 |
123 |
|
63x40 |
63/40 |
63x40 |
60 |
45 |
125 |
|
63x50 |
63/50 |
63x50 |
60 |
50 |
125 |
|
75x63 |
75/63 |
75x63 |
63 |
58 |
140 |
|
90x63 |
90/63 |
90x63 |
76 |
60 |
158 |
|
90x75 |
90/75 |
90x75 |
76 |
68 |
164 |
|
110x63 |
110/63 |
110x63 |
85 |
60 |
170 |
|
110x90 |
110/90 |
110x90 |
87 |
76 |
175 |
|
160x90 |
160/90 |
160x90 |
112 |
76 |
195 |
|
160x110 |
160/110 |
160x110 |
112 |
80 |
195 |
|
200x90 |
200/90 |
200x90 |
130 |
75 |
215 |
|
200x110 |
200/110 |
200x110 |
130 |
85 |
215 |
|
200x160 |
200/160 |
200x160 |
130 |
110 |
215 |
|
250x110 |
250/升10 |
250x110 |
161 |
85 |
255 |
|
250x160 |
250/160 |
250x160 |
161 |
116 |
255 |
|
250x200 |
250/200 |
250x200 |
161 |
136 |
255 |
