Butt Fusion Equal Tee

Our Butt Fusion Equal Tee is a standard part for PE pipe branch connections. It works for pipes of the same size. We follow all environmental laws in China and in export markets. Our factory has complete waste treatment systems. Every step of production is clean and legal. You do not need to worry about your project failing an environmental check. Our product has passed many factory audits from high-standard European buyers. It is a good choice for markets with strict green rules.

Send Inquiry

Description

Clean and Green Production

Strong Welding Performance

We have our own R&D team. They keep improving the mold design. They change the flow path inside the mold. This lowers the leftover stress inside the tee after molding. The result is better welding stability. The weld strength can match the pipe body itself. Our Butt Fusion Equal Tee uses over 30 years of pipe fitting experience. You get a reliable product for your pipeline. Before you buy, we offer one-to-one engineer support. They help you check the L1, L2, and L3 sizes against your drawings. For example, a DN315×315×315 equal tee has L1=592mm, and both L2 and L3 are 150mm. These sizes decide how the tee fits in your pipe network.

Free Sample for Testing

We want you to feel safe when you buy in bulk. So we give free samples. You can ask for a sample of our Butt Fusion Equal Tee. Then you can do a real welding test on site. You check all the results. Only after that do you sign a large order. This stops you from picking the wrong part. It lowers your buying risk. We make sure you get the right tee for your project. Our free sample policy is always open. Just contact us to get your sample.

Size dn1×dn2×dn1	Order No.	dn1×dn2×dn1	L1 (mm)	L2 (mm)	L3 (mm)
50×50×50	MT50/50/50	50×50×50	182	57	55
63×32×63	MT63/32/63	63×32×63	200	65	51
63×40×63	MT63/40/63	63×40×63	200	67	54
63×63×63	MT63/63/63	63×63×63	211	66	66
90×32×90	MT90/32/90	90×32×90	226	82	52
90×40×90	MT90/40/90	90×40×90	228	83	52
90×50×90	MT90/50/90	90×50×90	283	87	60
90×63×90	MT90/63/90	90×63×90	285	83	68
90×90×90	MT90/90/90	90×90×90	283	87	87
110×32×110	MT110/32/110	110×32×110	237	78	52
110×40×110	MT110/40/110	110×40×110	238	81	52
110×50×110	MT110/50/110	110×50×110	280	87	61
110×63×110	MT110/63/110	110×63×110	280	87	72
110×90×110	MT110/90/110	110×90×110	307	87	82
110×110×110	MT110/110/110	110×110×110	320	87	87
125×63×125	MT125/63/125	125×63×125	327	118	87
125×125×125	MT125/125/125	125×125×125	327	118	118
160×50×160	MT160/50/160	160×50×160	440	123	85
160×63×160	MT160/63/160	160×63×160	360	109	94
160×90×160	MT160/90/160	160×90×160	362	109	95
160×110×160	MT160/110/160	160×110×160	360	108	97
160×160×160	MT160/160/160	160×160×160	424	117	117
200×63×200	MT200/63/200	200×63×200	408	117	71
200×90×200	MT200/90/200	200×90×200	407	117	90
200×110×200	MT200/110/200	200×110×200	410	118	90
200×160×200	MT200/160/200	200×160×200	482	128	103
200×200×200	MT200/200/200	200×200×200	482	125	117
250×110×50	MT250/110/50	250×110×50	457	129	90
250×90×250	MT250/90/250	250×90×250	460	129	91
250×63×50	MT250/63/50	250×63×50	458	129	70
250×160×250	MT250/160/250	250×160×250	501	135	108
250×200×250	MT250/200/250	250×200×250	505	140	115
250×250×225	MT250/250/225	250×250×225	572	134	134
315×90×315	MT315/90/315	315×90×315	600	150	87
315×110×315	MT315/110/315	315×110×315	598	150	92
315×160×315	MT315/160/315	315×160×315	592	150	111
315×200×315	MT315/200/315	315×200×315	592	150	128
315×250×315	MT315/250/315	315×250×315	727	150	136
315×315×315	MT315/315/315	315×315×315	592	150	150
355×250×355	MT355/250/355	355×250×355	725	168	142
355×315×315	MT355/315/315	355×315×315	730	170	164
355×355×355	MT355/355/355	355×355×355	726	165	164
180×180×180	MT180/180/180	180×180×180	457	105	105
140×140×140	MT140/140/140	140×140×140	373	92	92
400×400×400	MT400/400/400	400×400×400	777	179	179
